Grandstream GXV3601

More Views

Grandstream GXV3601

SKU: gra-gxv3601

Availability: In stock

Cost effective, VoIP video surveillance camera. It features cutting edge H.264 real-time video compression with excellent image clarity at low-to-modest bandwidth usage.
Description

Details

The GXV3601 is a next generation IP camera of power and innovation. It features cutting edge H.264 real-time video compression (D1 resolution) with excellent image clarity at low-to-modest bandwidth, industry leading SIP/VoIP for full duplex 2-way audio and video streaming to mobile phones and video phones, integrated PoE, embedded analytics, large pre-/post-event recording buffer, and advanced security protection. Its unique incorporation of the most comprehensive peripheral support for alarm control, local storage expansion, and wireless network connection, creates sophisticated and best-in-class control flexibility and scalability. The GXV3601 can be managed with GSurf, Grandstream’s advanced and intuitive video management software that controls up to 36 cameras simultaneously. The GXV3601 is a powerful network camera for professional surveillance environments.

Additional Information

Additional Information

Manufacturer Grandstream
Core Features
Technical Info



GXV3601 Features & Benefits
  • High quality Sony CCD sensor and lens to ensure razor sharp picture quality
  • Advanced multi-streaming-rate real-time H.264, Motion JPEG at D1 resolution
  • Alarm input & output, audio input & output, RS485, iris control
  • 24MB pre-/post-event recording buffer
  • USB 2.0 port and SD slot for storage/wireless network card
  • Integrated Power-over-Ethernet (802.3af), optional antenna for wireless network
  • Embedded video analytics, SIP/VoIP support for full duplex two-way audio as well as video streaming to mobile phones and video phones
  • Built-in high performance streaming server to allow up to 16 simultaneous D1 viewers or 25 CIF viewers

Product Specifications
  • Video Compression
    • H.264, JPEG, Motion JPEG
  • Image Sensor
    • 1/3” SONY Super HAD CCD
  • Lens Type
    • 1/3” Varifocal 3.5-8mm, DC-iris, CS mount, changeable
  • Minimum Illumination (Lux) 0.015 at F1.4
    • Max Video Resolution Full D1: 720 x 576 (PAL), 720 x 480 (NTSC)
  • Max Frame Rate in Max Resolution
    • 30fps/25fps at D1 (NTSC/PAL)
  • Video Bit Rate
    • 32 Kbps – 2 Mbps
  • Video Output
    • BNC x 1, Voltage 1.0Vp-p, Resistance 75?
  • Audio Input
    • 3.5mm LINE-IN
  • Audio Output
    • 3.5mm LINE-OUT
  • Alarm Input
    • Yes – 1, Normal Open
  • Alarm Output
    • Yes – 1, 125VAC/0.5A, 30VAC/2A
  • Audio Compression
    • G.711, G.726
  • Serial Ports
    • RS485
  • IRIS Control
    • Yes
  • Embedded Analytics
    • Motion detection (up to 16 target areas), video loss (pending)
  • Pre-/post-alarm Buffer
    • 24MB
  • Snapshots
    • Trigger upon events, send via email/FTP
  • Multi-streaming-rate for Preview & Recording
    • Yes
  • Security
    • Video watermark, HTTPS, Password
  • Network Port
    • 10M/100M auto-sensing, RJ45
  • Network Protocol
    • TCP/UDP/IP, RTP/RTCP, RTSP, DHCP, PPPoE, DDNS, HTTP, HTTPS
  • Power over Ethernet (PoE)
    • Standard, IEEE 802.3af Class 3
  • Peripheral Ports
    • SD 2.0, USB 2.0
  • Wi-Fi (802.11b/g)
    • 5dB external antenna (GXV3601W only)
  • SIP/VoIP Support
    • Yes
  • Power
    • Output: 12VDC/1A; Input:100–240VAC, 50–60Hz
